Jack Northrop Field Hawthorne Municipal airport (United State) NOTAM and informations KHHR HHR

ODP JACK NORTHROP FLD/HAWTHORNE MUNI, HAWTHORNE, CA.

TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 5...

CHANGE RUNWAY 25 TAKEOFF MINIMUMS TO READ: RUNWAY 25: 300-1 3/4 OR STANDARD WITH MINIMUM CLIMB OF 290 FEET PER NM TO 300.

ALL OTHER DATA REMAINS AS PUBLISHED. 2309221246-2509221246EST

ODP JACK NORTHROP FLD/HAWTHORNE MUNI,

HAWTHORNE, CA.

TAKEOFF MINIMUMS AND (OBSTACLE) DEPARTURE PROCEDURES AMDT 5...

DEPARTURE PROCEDURE TAKEOFF OBSTACLES.

CHANGE TO READ: RWY 7: POLE 16 FT FROM DER, 142 FT LEFT OF

CENTERLINE, 25 FT AGL/77 FT MSL.

TREE, WALL, POLE, VEHICLES ON ROAD, FENCE, SIGN, BUILDING BEGINNING

23 FT FROM DER, 3 FT LEFT OF CENTERLINE, UP TO 52 FT AGL/114 FT

MSL.

POLE 29 FT FROM DER, 395 FT RIGHT OF CENTERLINE, 30 FT AGL/89 FT

MSL.

SIGN, POLE, WALL, FENCE, LIGHT POLES, VEHICLES ON ROAD, TREE,

BUILDING BEGINNING 78 FT FROM DER, ON CENTERLINE, UP TO 38 FT

AGL/94 FT MSL.

TREE, POLE, VEHICLES ON ROAD, BUILDING, SIGN BEGINNING 476 FT FROM

DER, 39 FT LEFT OF CENTERLINE, UP TO 136 FT MSL.

BUILDING, POLE BEGINNING 759 FT FROM DER, 96 FT RIGHT OF

CENTERLINE, UP TO 42 FT AGL/102 FT MSL.

POLE 1465 FT FROM DER, 203 FT RIGHT OF CENTERLINE, 38 FT AGL/103 FT

MSL.

POLE BEGINNING 1489 FT FROM DER, 20 FT RIGHT OF CENTERLINE, UP TO

41 FT AGL/111 FT MSL.

AGL/280 FT MSL..

END PART 1 OF 8

ODP JACK NORTHROP FLD/HAWTHORNE MUNI,

HAWTHORNE, CA.

TREES BEGINNING 2120 FT FROM DER, 110 FT LEFT OF CENTERLINE, UP TO

63 FT AGL/137 FT MSL.

TREE, POLE BEGINNING 2163 FT FROM DER, 84 FT LEFT OF CENTERLINE, UP

TO 66 FT AGL/147 FT MSL.

BUILDING BEGINNING 2168 FT FROM DER, 264 FT RIGHT OF CENTERLINE, UP

TO 36 FT AGL/116 FT MSL.

TREE, POLE BEGINNING 2704 FT FROM DER, 112 FT LEFT OF CENTERLINE,

UP TO 72 FT AGL/161 FT MSL.

POLE, TREE BEGINNING 2799 FT FROM DER, 54 FT RIGHT OF CENTERLINE,

UP TO 61 FT AGL/148 FT MSL.

TREE, POLE BEGINNING 2876 FT FROM DER, 27 FT LEFT OF CENTERLINE, UP

TO 78 FT AGL/168 FT MSL.

TRANSMISSION LINE, POLE, TREE BEGINNING 2893 FT FROM DER, 65 FT

RIGHT OF CENTERLINE, UP TO 70 FT AGL/157 FT MSL.

POLE 3192 FT FROM DER, 172 FT RIGHT OF CENTERLINE, 62 FT AGL/160 FT

MSL.

TREES BEGINNING 3207 FT FROM DER, 81 FT RIGHT OF CENTERLINE, UP TO

67 FT AGL/167 FT MSL.

TREE, POLE BEGINNING 3304 FT FROM DER, 8 FT LEFT OF CENTERLINE, UP

TO 170 FT MSL.

AGL/280 FT MSL..

END PART 2 OF 8

ODP JACK NORTHROP FLD/HAWTHORNE MUNI,

HAWTHORNE, CA.

TREES BEGINNING 3497 FT FROM DER, 117 FT RIGHT OF CENTERLINE, UP TO

71 FT AGL/178 FT MSL.

TREE, POLE, ANTENNA, BUILDING BEGINNING 3712 FT FROM DER, 102 FT

LEFT OF CENTERLINE, UP TO 65 FT AGL/179 FT MSL.

TREE, POLE BEGINNING 3719 FT FROM DER, 2 FT RIGHT OF CENTERLINE, UP

TO 74 FT AGL/188 FT MSL.

TREE 3850 FT FROM DER, 1301 FT LEFT OF CENTERLINE, 41 FT AGL/180 FT

MSL.

TREE, POLE BEGINNING 3859 FT FROM DER, 23 FT LEFT OF CENTERLINE, UP

TO 51 FT AGL/185 FT MSL.

TREE, POLE BEGINNING 4061 FT FROM DER, 28 FT LEFT OF CENTERLINE, UP

TO 203 FT MSL.

TREE 4074 FT FROM DER, 290 FT RIGHT OF CENTERLINE, 69 FT AGL/190 FT

MSL.

TREE 4079 FT FROM DER, 411 FT RIGHT OF CENTERLINE, 82 FT AGL/202 FT

MSL.

TREE, POLE BEGINNING 4101 FT FROM DER, 17 FT RIGHT OF CENTERLINE,

UP TO 90 FT AGL/211 FT MSL.

TREE, POLE BEGINNING 4323 FT FROM DER, 32 FT LEFT OF CENTERLINE, UP

TO 52 FT AGL/212 FT MSL.

AGL/280 FT MSL..

END PART 3 OF 8

ODP JACK NORTHROP FLD/HAWTHORNE MUNI,

HAWTHORNE, CA.

TREE, POLE, BUILDING BEGINNING 4484 FT FROM DER, 3 FT LEFT OF

CENTERLINE, UP TO 66 FT AGL/235 FT MSL.

POLE, TREE BEGINNING 4932 FT FROM DER, 31 FT LEFT OF CENTERLINE, UP

TO 46 FT AGL/236 FT MSL.

BUILDING, POLE BEGINNING 4949 FT FROM DER, 46 FT RIGHT OF

CENTERLINE, UP TO 66 FT AGL/214 FT MSL.

TREE, POLE, BUILDING BEGINNING 4989 FT FROM DER, 1 FT RIGHT OF

CENTERLINE, UP TO 220 FT MSL.

TREE, POLE, BUILDING BEGINNING 5058 FT FROM DER, 44 FT LEFT OF

CENTERLINE, UP TO 241 FT MSL.

ANTENNA, TOWER, TREE, BUILDING, SIGN, FENCE BEGINNING 5140 FT FROM

DER, 93 FT LEFT OF CENTERLINE, UP TO 55 FT AGL/243 FT MSL.

TREE, POLE BEGINNING 5202 FT FROM DER, ON CENTERLINE, UP TO 78 FT

AGL/227 FT MSL.

TREE, SIGN BEGINNING 5356 FT FROM DER, 55 FT LEFT OF CENTERLINE, UP

TO 54 FT AGL/249 FT MSL.

TREE, POLE BEGINNING 5383 FT FROM DER, 62 FT RIGHT OF CENTERLINE,

UP TO 102 FT AGL/257 FT MSL.

TOWER, TRANSMISSION LINE, POLE, SIGN, BUILDING, TREE, ELEVATOR

BEGINNING 5428 FT FROM DER, 35 FT LEFT OF CENTERLINE, UP TO 139 FT

AGL/280 FT MSL..

END PART 4 OF 8

ODP JACK NORTHROP FLD/HAWTHORNE MUNI,

HAWTHORNE, CA.

AGL/307 FT MSL.

TOWER, TREE BEGINNING 1.2 NM FROM DER, 1711 FT LEFT OF CENTERLINE,

UP TO 115 FT AGL/322 FT MSL.

BUILDING, MONUMENT, TREE, TOWER, ANTENNA, TRANSMISSION LINE, POLE

BEGINNING 1.2 NM FROM DER, 205 FT LEFT OF CENTERLINE, UP TO 104 FT

AGL/328 FT MSL.

TREE 1.3 NM FROM DER, 16 FT RIGHT OF CENTERLINE, 76 FT AGL/278 FT

MSL.

TOWER 1.4 NM FROM DER, 824 FT RIGHT OF CENTERLINE, 116 FT AGL/289

FT MSL.

TOWER 1.4 NM FROM DER, 317 FT RIGHT OF CENTERLINE, 119 FT AGL/302

FT MSL.

RWY 25: SIGN 24 FT FROM DER, 100 FT LEFT OF CENTERLINE, 3 FT AGL/67

FT MSL.

POLE, BUILDING, LIGHT POLES, TREE, FENCE, VEHICLES ON ROAD, SIGN,

ANTENNA BEGINNING 51 FT FROM DER, ON CENTERLINE, UP TO 38 FT

AGL/105 FT MSL.

NAVAID 72 FT FROM DER, 1 FT LEFT OF CENTERLINE, 8 FT AGL/73 FT MSL.

BUILDING, POLE, FENCE BEGINNING 112 FT FROM DER, 183 FT LEFT OF

CENTERLINE, UP TO 30 FT AGL/95 FT MSL.

AGL/280 FT MSL..

END PART 5 OF 8

ODP JACK NORTHROP FLD/HAWTHORNE MUNI,

HAWTHORNE, CA.

POLE, FENCE, TREE, SIGN BEGINNING 158 FT FROM DER, 5 FT LEFT OF

CENTERLINE, UP TO 38 FT AGL/102 FT MSL.

POLE, VEHICLES ON ROAD, TREE, SIGN BEGINNING 206 FT FROM DER, 38 FT

LEFT OF CENTERLINE, UP TO 39 FT AGL/103 FT MSL.

TREE, VEHICLES ON ROAD, SIGN, BUILDING, POLE BEGINNING 258 FT FROM

DER, 5 FT LEFT OF CENTERLINE, UP TO 40 FT AGL/105 FT MSL.

POLE, ANTENNA, BUILDING, TREE BEGINNING 423 FT FROM DER, 39 FT LEFT

OF CENTERLINE, UP TO 41 FT AGL/107 FT MSL.

TREE, ANTENNA, BUILDING, VEHICLES ON ROAD, POLE BEGINNING 449 FT

FROM DER, 5 FT LEFT OF CENTERLINE, UP TO 122 FT MSL.

POLE, TREE, ANTENNA BEGINNING 670 FT FROM DER, 7 FT RIGHT OF

CENTERLINE, UP TO 54 FT AGL/120 FT MSL.

TREE, POLE BEGINNING 1031 FT FROM DER, 27 FT LEFT OF CENTERLINE, UP

TO 62 FT AGL/128 FT MSL.

TREE, POLE BEGINNING 1054 FT FROM DER, 12 FT RIGHT OF CENTERLINE,

UP TO 136 FT MSL.

TREES BEGINNING 2208 FT FROM DER, 32 FT RIGHT OF CENTERLINE, UP TO

78 FT AGL/144 FT MSL.

TREES BEGINNING 2218 FT FROM DER, 41 FT LEFT OF CENTERLINE, UP TO

65 FT AGL/131 FT MSL.

AGL/280 FT MSL..

END PART 6 OF 8

ODP JACK NORTHROP FLD/HAWTHORNE MUNI,

HAWTHORNE, CA.

TREE, BUILDING BEGINNING 2222 FT FROM DER, 3 FT RIGHT OF

CENTERLINE, UP TO 79 FT AGL/145 FT MSL.

TREES BEGINNING 2229 FT FROM DER, 152 FT LEFT OF CENTERLINE, UP TO

66 FT AGL/132 FT MSL.

TREE 2239 FT FROM DER, 344 FT LEFT OF CENTERLINE, 67 FT AGL/135 FT

MSL.

TREES BEGINNING 2249 FT FROM DER, 11 FT LEFT OF CENTERLINE, UP TO

80 FT AGL/147 FT MSL.

BUILDING, FENCE, TREE BEGINNING 2423 FT FROM DER, 148 FT LEFT OF

CENTERLINE, UP TO 83 FT AGL/154 FT MSL.

POLE, TREE BEGINNING 2740 FT FROM DER, 360 FT RIGHT OF CENTERLINE,

UP TO 77 FT AGL/149 FT MSL.

TREES BEGINNING 3179 FT FROM DER, 207 FT RIGHT OF CENTERLINE, UP TO

74 FT AGL/150 FT MSL.

TREE 3222 FT FROM DER, 228 FT RIGHT OF CENTERLINE, 76 FT AGL/153 FT

MSL.

TANK 4537 FT FROM DER, 1313 FT LEFT OF CENTERLINE, 137 FT AGL/227

FT MSL.

WATER TOWER 4539 FT FROM DER, 1321 FT LEFT OF CENTERLINE, 132 FT

AGL/229 FT MSL.

AGL/280 FT MSL..

END PART 7 OF 8

ODP JACK NORTHROP FLD/HAWTHORNE MUNI,

HAWTHORNE, CA.

BUILDING 1.3 NM FROM DER, 2515 FT RIGHT OF CENTERLINE, 190 FT

AGL/280 FT MSL..

END PART 8 OF 8

IAP JACK NORTHROP FLD/HAWTHORNE MUNI, HAWTHORNE, CA.

VOR RWY 25, AMDT 16B...

MISSED APPROACH: CHANGE MISSED APPROACH TO READ: CLIMBING LEFT TURN TO 3000 ON HEADING 210 AND LAX VORTAC R-170 TO LIMBO INT/LAX 10.4 DME AND HOLD, CONTINUE CLIMB-IN-HOLD TO 3000.

2309221251-2509221251EST

IAP JACK NORTHROP FLD/HAWTHORNE MUNI, HAWTHORNE, CA.

RNAV (GPS) RWY 7, ORIG...

PROCEDURE NA.

2503031601-2510131601EST

COM REMOTE COM OUTLET 243.0 U/S

OBST TOWER LGT (ASR 1233172) 335538.30N1181837.20W (1.3NM ENE HHR) 243.1FT (58.1FT AGL) U/S

/FIM/ NAV TACAN AZM U/S

OBST TOWER LGT (ASR 1011103) 335545.00N1181808.20W (1.7NM ENE HHR) 319.9FT (105.0FT AGL) U/S

OBST TOWER LGT (ASR 1215350) 335647.80N1181839.40W (1.8NM NE HHR) 325.8FT (89.9FT AGL) U/S

RWY 25 ALS U/S

IAP JACK NORTHROP FLD/HAWTHORNE MUNI, HAWTHORNE, CA.

LOC RWY 25, AMDT 12C...

MISSED APPROACH: CLIMBING LEFT TURN TO 3000

ON HEADING 210 AND SMO VOR/DME R-164 TO LIMBO/SMO 15.02

DME AND HOLD; (DME REQUIRED).

DME REQUIRED EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,

SLI VORTAC OUT OF SERVICE. 2507021419-2511011419EST

IAP JACK NORTHROP FLD/HAWTHORNE MUNI, HAWTHORNE, CA.

VOR RWY 25, AMDT 16B...

PROCEDURE NA EXCEPT FOR ACFT EQUIPPED WITH SUITABLE RNAV SYSTEM WITH GPS,

SLI VORTAC OUT OF SERVICE. 2507021419-2511011419EST

OBST CRANE (ASN UNKNOWN) 335544N1181826W (2NM W HHR) 319FT (123FT AGL) FLAGGED AND LGTD
